50mm2 General-Purpose Heavy Duty - BLACK

Black Cable

Quantity:

Our 50mm² Single Core Battery and Welding Cable (Rated at 345 Amps) is easy to install as it is highly flexible, whilst remaining seriously durable.

Copper conductor with PVC insulation, (resistant to oils, petrol, diesel, lubes and a range of diluted acids).

Manufactured in accordance to CE, ROHS, ISO and EN numbers where applicable.

Easy to strip for speedy stress free usage.

Remember to consider voltage drop when deciding which cable to use! Use our Votage Drop Calculator to help calculate the voltage drop for your cable.

Electrical

Nominal Rating

345A

Outer Cable Diameter

13.80 ±0.15mm

Average Insulation Thickness

1.70mm

Minimum Insulation Thickness

1.53mm

Nominal Conductor Construction

636/0.30mm

Maximum Cond. Resistance at 20^oC

0.419 Ohms
